SBus boards

S11W

The S11W is a discontinued product, and is no longer supported. This information is is provided for reference only. Features Sun SPARCstation Compatible Single SBus Slot Rates to 8 megabytes per second Supports SBus 1 6-byte Burst mode Supports all standard DR11W Modes except byte writes Supports additional buffered block modes with internal FIF0 Programmable […]

S16D

The S16D is discontinued, and is no longer supported. The information on this page is provided for reference only. Features Sun SPARCstation compatible Single SBus slot Continuous input or output Rates to 10 megabytes per second Supports Sbus 16-byte burst mode Supports buffered block modes with internal FIFO Programmable control signal configurations 4 gigabyte DVMA addressing […]

S53B-1

The S53B-1 is a discontinued product, and is no longer supported. This information is is provided for reference only. Features Sun SPARCstation compatible Error insertion and detection capabilities Supports minimum 4 microsecond intermessage gap and RT response Single SBus slot Powerful real-time bus controller scheduling capabilities on board Simultaneously acts as single or multiple Remote […]

SCD-20

The SCD-20 is a discontinued product, and is no longer supported. This information is is provided for reference only. Features Transfer rates up to 20 MB per second. 1 KByte FIFO Implements a high speed DMA channel between an external device and Sun SPARCstation RS-422 compatible driver/receivers Customizable by a RAM-based programmable gate array Synchronous […]

SCD-60

The SCD-60 is a discontinued product, and is no longer supported. This information is provided for reference only. Features Implements a high speed DMA channel between an external device and host computer. Transfer rates up to 60 MB per second. 2 KByte FIFO EIA-644 LVDS compatible driver/receivers Customizable by a RAM based programmable gate array […]

SSD4

The SSD4 is a discontinued product, and is no longer supported. This information is provided for reference only. Features Serial rates up to 15 Mbits/sec 1, 2, or 4 channels per board Independent clock per channel Programmable 1, 2, or 4 data bits per clock RS422 compatible driver/receivers SunSPARCstation compatible TTL compatible driver/receivers with special […]
